Specifications
System Specifications System Specifications
Frequency Response 20Hz to 20kHz +/ - 0.5 dB
Dynamic range 95 dBu, un-weighted, 22 Hz to 22 kHz
THD 0.008 % typ. @ +4 dBu, 1 kHz
Crosstalk 90dB, 22 Hz to 22 kHz
Detector RMS
Gate
Trigger range variable (-50 to +20 dB)
Attack variable (0.3 to 3000ms)
Release variable (0.02 to 5 sec.)
Hold variable (0.01 to 4 sec.)
Range variable (0 to 100 dB)
DUCKER Section
RANGE variable (1 to 100 dB )
Function Switches
Link Linking two channels for stereo operation. Channel 1
becomes master for Channel 2. Channel 3 becomes
master for Channel 4.
Filter
Key Listen
Ducker
In/Out
Meters & LED's
Gain Reduction 8 segment LED display:
30/24/18/12/6/4/2/1 dB
Gate Activity 3 segment LED display:
green-open; yellow-hold; red-closed
