2
- ASSEMBLY OF THE FREEZER DOOR
REVERSING THE DOOR SWING
19. Switch the position of the CAP HOLE
HINGE UPP.
20. Reconnect the electric wires and
reposition the wires inside of the CAP
CABI as shown below.
21. Reassemble the CAP CABI, after assuring
the position of Wires.
23. Exchange the positions of a bolt and the
ASSY HINGE LOW.
24. Fit the Freezer Door into the ASSY
HINGE MID.
22. Switch the position of the GROMMET
HINGE and the CAP HINGE HOLE.
CAPHOLE
HINGE UPP
CAP CABI
