Supplied Parts and Hardware
Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the item
to your dealer; contact Sanus Systems Customer Service. Never use damaged parts!
x 1
10-24 x 0.25 in.
x 1
10-24 x 0.25 in.
x 1
10-24 x 0.25 in.
203 mm
(8.0 in.)
203 mm
(8.0 in.)
165 mm
(6.5 in.)
165 mm
(6.5 in.)
82 mm
(3.25 in.)
19 mm
(0.75 in.)
82 mm
(3.25 in.)
1-1/2 in. NPT
11 x 19 mm
(0.44 x 0.75 in.)
19 mm
(0.75 in.)
10-24 x 0.25 in.
17 mm
(0.68 in.)
