16
Connecting to a Power Source
Using the batteries
Battery status
Battery indicator
The batteries are fully
charged.
Prepare new batteries.
There is no battery capacity.
Replace with new batteries.
There are 3 indicators for battery condition that are displayed on the LCD monitor.
Removing the battery
1. Turn off the camera power. Open the battery chamber
cover and unlock the battery by pushing the battery lock
lever. The battery will pop up slightly.
2. Remove the battery in the direction indicated and close the
battery chamber cover.
: If the camera does not turn on after you have inserted batteries,
please check whether the batteries are inserted with the
polarity(+and-)
1. Open the battery chamber
cover by pushing in the
direction of the arrow.
2. Insert the batteries
according to the polarity
marks (+ and -) on the
back of the battery
chamber cover.
3. To close the battery
chamber cover, push it
until it clicks.
