Samsung Digimax U-CA 401 - Manual (Page 13)

13
Identification of features
Still image mode
You can select from AUTO( ), Night( ),
MYSET( ), TEXT( ) modes.
Lamp
Type Function Lamp Camera Status Lamp LCD Monitor
When turning on the
power
Blue lamp blink and then turns off when
the camera is ready to take a picture
Green lamp blinks X
When the camera is in focus (when the
SHUTTER button is pressed halfway)
X Green lamp lights up
Autofocus mark
lights up green
When the camera is out of focus (when
the SHUTTER button is pressed halfway)
X Green lamp blinks
Autofocus mark
lights up red
While the flash is charging X Red lamp blinks X
While saving an image X Green lamp blinks X
While shooting a video X Green lamp blinks X
During voice recording The blue lamp blinks in a sequence. X X
While the camera is connected to a PC X Green lamp lights up X
While transferring data between the camera and a PC X Green lamp blinks X
When shooting an image Blue lamp blinks once for 1 second X X
Flash is ready (when the SHUTTER
button is pressed halfway)
X Red lamp lights up X
While the self-timer is
running
When the self-timer is activated,
for the first seven seconds, the
blue lamp blinks at 1 second
intervals. For the final three
seconds, the blue lamp blinks
rapidly at 0.25-second intervals.
Green lamp lights up
Autofocus mark
lights up green
When the LCD monitor is
turned off in Still Image mode
Green lamp lights up X X
