Intermediate Frame Snowthrowers

6/2006

3

TP 300-5196-00-IS-SN

Quick Setup List -

Page

Setup Procedure

Steps to Perform

4

Uncrating

4

Reduce Tire Pressures

❏ Reduce Tire Pressure to 20 psi (137 kPa) & Check

4

Assembly

❏ Install Drift Cutters

5

Assembly

❏ Un-Folding Handles
❏ Connecting Shift Rods

6

Assembly

❏ Spout Rotator
❏ Control Levers
❏ Clean-Out Tool

7

Check Fluid Levels & Fill

❏ Auger Gearcase
❏ Engine Crankcase
❏ Fuel Tank

7

Lubricate Snowthrower

❏ Lubricate all grease & oil points

8

Lubricate Snowthrower

❏ Lubricate the auger Shaft & Assembly

9

Perform Safety Checks

Functional Checks
❏ Check that all Safety Guards are in place.
❏ Check Scraper Bars & Skid Shoe Height
❏ Check Drive Control & Auger Control
❏ Check Chute Direction Control
❏ Check Chute Deflector Control
❏ Check Speed Selector Control

Operational Checks
❏ Start Engine & Test ALL Controls
❏ Test Auger Stopping Time (Auger MUST stop within

5 seconds after the control is released.)

❏ Test Drive Controls
❏ Check For Fluid Leaks
