SPECIFICATIONS
Model .................................................................................................................. EB501
Dimensions (L x W x H) ..............................................................330 x 375x 475 mm
Engine Type ................... 2 cycle, catalyst, air cooled gas engine, vertical-cylinder
Bore & Stroke.............................................................. 41 x 33 mm (1.6 x 1.3 inches)
Displacement ........................................................................ 43.6 cc (2.66 cu. inches)
Fuel/oil ratio ............. Gasoline/oil mixture (50:1 with ISO EGD or JASO FC class
2- cycle EngineOil)
Carburetor ............................................. Walbro diaphragm-type with primer pump
Ignition ........................................................All transistor electronic ignition system
Spark Plug ..............................................................................................Champion CJ8
Starting .................................................................................................... Recoil starter
Stopping ......................................................................... Throttle lever (fuel shut-off)
Fuel Tank Capacity ...........................................................................2.1 liters (71 oz.)
Exhaust System .......................................................................Spark-arrester muffler
Air Filtration .............................................................................................Dry element
Weight (dry; without blower tubes), EB501 .....................................8.6 kg (19 lbs.)
Specifications are subject to change without notice.
1. Place the blower upright on the
ground or a sturdy work surface.
2. Fit the 90° discharge tube over the
blower outlet port, and secure with
the 115mm dia. clamp.
3. Slip the flexible tube over the oppo-
site end of the 90° discharge tube,
and secure with the 100mm clamp.
4. Push the swivel tube into the
flexible tube, and then install and
tighten the 85mm clamp over the
rotating band on the swivel tube.
5. Slide the handgrip over the swivel
tube, and secure with the bolt,
washer, and nut.
ASSEMBLING THE BLOWER
Prior to Assembly
Before assembling, make sure you
have all the components required for a
complete unit:
n
90° Discharge Tube
n
Flexible Tube
n
Swivel Tube
n
Straight Tube
n
Nozzle Tube
n
Handgrip (removable)
n
Three Tube Clamps (115 mm,
100 mm, 85 mm) See figure 2.
Standard Tools
n
Spark Plug Wrench
n
Three Hex Wrenches
(3 mm, 4mm, 5mm)
