• 6 •
Toggle the Work Light switch to the ON position. 3.
The Instant Power™ light will turn on and illuminate your work area. 4.
Toggle the Work Light switch to the OFF position when the work is completed. 5.
Charge the Instant Power™ as soon as possible after using the built-in light. 6.
Using the Air Compressor (Models XJS7C and XP750C) 7.5
RISK OF EXPLOSION.
Read the instructions of the product being inflated before using the compressor.
Avoid overinflation, do not exceed the manufacturer’s recommended pressures.
Do not leave the air compressor unattended during use.
NOTE: Before you use the compressor for the first time, you must install
the compressor hose wrap cleats. To install: Press each cleat into its
corresponding mounting holes on the back of the jump starter until it clicks into place.
Wrap the compressor hose around these cleats when it is not being used.
Ensure the battery clips are securely on the storage holders. 1.
Remove the air compressor hose from the storage cleats on the back of the Instant 2.
Power™. Install adapters as necessary.
Attach the air compressor hose to the product or accessory to be inflated by flipping
3.
down the lever.
Toggle the Compressor Switch up to the ON position and inflate the product.
4.
When the product is inflated to the proper air pressure (using the air compressor 5.
gauge), toggle the Compressor Switch down to the OFF position and remove the hose.
Do not run for more than 10 minutes maximum at a time. Allow the Instant Power™
6.
to cool down for 10 minutes before using again.
NOTE: To prevent overheating, the compressor has built-in thermal protection that
will turn the compressor off before it overheats. If the compressor shuts off, wait a few
minutes and it will automatically restart when the compressor cools.
NOTE: The air compressor is rated for 150 PSI.
MAINTENANCE INSTRUCTIONS
8.
After use and before performing maintenance, unplug and disconnect the Instant 8.1
Power™ (see sections 3 and 4).
Use a dry cloth to wipe all battery corrosion and other dirt or oil from the battery clips,
8.2
cords, and the Instant Power™ case.
Ensure that all of the Instant Power™ components are in place and in good
8.3
working condition.
Servicing does not require opening the unit, as there are no user-serviceable parts.
8.4
All other servicing should be performed by qualified service personnel. 8.5
MOVING AND STORAGE INSTRUCTIONS 9.
Store the Instant Power™ in an upright position. 9.1
Store inside, in a cool, dry place. 9.2
Do not store the clips on the handle, clipped together, on or around metal, or clipped 9.3
to cables. The clips on the Instant Power™ are live and will produce arcing or sparking
if they come in contact with each other. To prevent accidental arcing, always keep the
clips on the storage holders when not using it to jump start a vehicle.
If the Instant Power™ is moved around the shop or transported to another location, take
9.4
care to avoid/prevent damage to the cords, clips and Instant Power™. Failure to do so
could result in personal injury or property damage.
Do not use and/or store the Instant Power™ in or on any area or
surface where damage could occur if the internal battery should
unexpectedly leak acid.
IMPORTANT: 9.5
CHARGE IMMEDIATELY AFTER PURCHASE •
KEEP FULLY CHARGED •
Charge the Instant Power™ internal battery immediately after purchase, after every
use and every 30 days.
