• 3 •
INSTANT POWER 4. ™ LOCATION
RISK OF EXPLOSION AND CONTACT WITH
BATTERY ACID.
Locate the Instant Power™ as far away 4.1
from the battery as the DC cables permit.
Never place the Instant Power™ 4.2
directly above the battery being jumped; gases
from the battery will corrode and damage the Instant Power™.
Do not operate the Instant Power™ in a closed-in area or restrict the ventilation in any way.
4.3
FEATURES 5.
2
5
6
7
3
8
9
4
1
XJS7C and XP750C
Battery Status Indicators 1.
Battery Status Switch 2.
12V DC Power Outlet 3.
Battery Clips/USB ON/OFF Switch 4.
USB Port 5.
Built-In Worklight 6.
Worklight ON/OFF Switch 7.
Air Compressor Hose 8.
Battery Clips 9.
Internal Battery Charger Plug 10.
(not shown)
Air Compressor ON/OFF Switch
11.
(not shown)
Air Compressor Gauge (not shown)
12.
Air Compressor Hose Wrap Cleats 13.
(not shown)
Air Compressor Adapters and
14.
Storage Bag (not shown)
2
3
4
5
8
7
6
1
XJS5 and XP500
Battery Status Indicators 1.
Battery Status Switch 2.
Built-In Worklight 3.
Worklight ON/OFF Switch 4.
12V DC Power Outlet 5.
Battery Clips/USB ON/OFF Switch 6.
USB Port 7.
Battery Clips 8.
Internal Battery Charger Plug 9.
(not shown)
2
3
4
5
6
1
XJS4 and XP400
Battery Status Indicators 1.
Battery Status Switch 2.
Built-In Worklight 3.
Worklight ON/OFF Switch 4.
12V DC Power Outlet 5.
Battery Clips 6.
Internal Battery Charger Plug 7.
(not shown)
