5
Connection Panels
HEADPHONE JACK
Side of TV
Rear of TV
RCA AUDIO/VIDEO
INPUT CONNECTORS
SCART AUDIO/VIDEO
INPUT/OUTPUT CONNECTORS
75
Ω
Ω COAXIAL CONNECTOR
FOR AERIAL/CABLE NETWORK
â
These figures show typical connector-jack panels. The actual
configuration on your TV may be different, depending on your model.
S-VIDEO JACK
HEADPHONE JACK
RCA AUDIO/VIDEO
INPUT CONNECTORS
HEADPHONE JACK
RCA AUDIO/VIDEO INPUT CONNECTORS
RCA MONITOR OUTPUT CONNECTORS
(OPTION)
Front of TV
ENG
