Chapter 4 Adjustments and Settings for Recording
4-10(E)
Chapter 4 Adjustments and Settings for Recording
6 Gain value display
Displays the video gain value (dB) set with the GAIN
switch.
7 Focus position
Shows the focus position of a zoom lens as a numeric
value (0 to 255 (infinity)).
8 Battery voltage
Displays the input voltage.
9 F value
Indicates the lens F (iris opening) value.
0 Tape remaining
Displays the VTR tape time remaining (in minutes).
“5-0” is displayed when the remaining time is less than
five minutes, “10-5” is displayed for 5 to 10 minutes
remaining, “15-10” is displayed for 10 to 15 minutes
remaining, and “F-15” is displayed when greater than
15 minutes remain.
Nothing is displayed if a VTR is not connected.
qa Shutter/EVS
Displays the shutter/EVS status. Nothing is displayed
if both the electronic shutter and EVS are set to OFF.
4-4 Viewfinder Screen Status Display
