STUDER INNOTEC

HP-COMPACT

HP-COMPACT

V5.4

15/80

4.2 Light Emitting Diodes (LED)

LED

Marking

LED lit

LED blinks

1 AC

IN

Voltage
corresponding to
self-adjusted
values is at the AC
IN input.

A voltage outside the self-adjusted
values is at the AC IN input, or the
HP-COMPACT is in synchronization
phases

2 CHARGER

Battery charger is
working

The battery charger is locked OFF
(see chap. 4.6) or provisory out of
order. In that last case it will restart
within 10 seconds

3 Reserved

4 Program

Program mode for
Aux. Contact

5

Contact

active

Auxiliary Contact is
activated

6

Contact

manual

Aux. Cont.
manually activated

7 TRANSFER

Transfer system is
active. In- coming
voltage is being
sent directly to AC
OUT outlet

Transfer (bypass) is disabled (see
chap. 4.7)

8 AC

OUT

There is a voltage
at the AC OUT
outlet

The Inverter is in Standby-Mode

9 INVERTER

Inverter

is

working

Forced Inverter Mode (see chap. 4.5)

10 Over

Temp.

For the time being
the HP-COMPACT
is out of service
because of
overheating.

11 Overload

The HP-
COMPACT is out
of service because
of overload or
short-circuit

12

Batt.

Low/High

Battery voltage is
too low

Battery voltage is or was to high

13 OFF

HP-COMPACT is
turned off. Turning
it back on is only
possible manually.

HP-COMPACT is for the time being
turned off. Turning it back on will
follow automatically !

14 EQUALIZE

Battery equalizing
is set

15–18

State of charge of
the battery

LED 15 – Absorption time is running
