STA-RITE Swimming Pool Filter - Manual (Page 5)

PLM100JWAE-06 PLM100JWAF-06
PLM150JWAE-06 PLM150JWAF-06
Adapters, Clamps, and Canadian Spec. Motor
(Includes 25’ Cord w/Straight Plug)
PLM100JWAE-12 PLM100JWAF-12
PLM150JWAE-12 PLM150JWAF-12
Adapters, Clamps, and U.S.A. Spec. Motor
(Includes 3’ Cord w/Twist-Lok Plug)
PLM100JWAE-03 PLM100JWAF-03
PLM150JWAE-03 PLM150JWAF-03
Hoses, Adapters, Clamps, and U.S.A. Spec. Motor
(Includes 3’ Cord w/Straight Plug)
PLM100JWAE-04 PLM100JWAF-04
PLM150JWAE-04 PLM150JWAF-04
Adapters, Clamps, and U.S.A. Spec. Motor
(Includes 3’ Cord w/Straight Plug)
5
43.5"
(1105 mm)
Minimum
Service
Height
32.75"
(832 mm)
19.5" (495 mm)
15" (381 mm)
Inlet
2" NPT
Outlet
2" NPT
Drain
Plug
Lower
Tank
Shell
Safety
Latch
Posi-Lok™
Ring
Upper
Tank
Shell
Air Release Valve
(Pressure Gauge
Behind)
2157 1295
Pump
Suction
1-1/2" NPT
30" (762 mm)
11"
(279 mm)
7.4"
(188 mm)
2" NPT x 1-1/2" NPT
Reducer Bushing
2 (14)
4 (28)
6 (41)
8 (55)
10 (69)
12 (88)
14 (97)
16 (110)
18 (124)
20 (138)
22 (152)
24 (165)
Pressure Drop in Pounds per Square Inch (kPa)
10
(38)
20
(76)
40
(151)
60
(227)
80
(303)
100
(378)
120
(454)
140
(529)
150
(568)
160
(606)
Flow in Gallons Per Minute (LPM)
2497 0796
SPECIFICATIONS / MODEL DESCRIPTIONS
FIGURE 1 – Dimensions in inches (mm)
Table 1 - Filter Specifications
Model No.
PLM100 PLM150
Filter Area sq. ft. (m 2 ) 100(9.3) 150(14)
Max. Rated Flow GPM (LPM)*
Residential 100(379) 150(568)
Commercial 37(140) 56(212)
Max. Operating Pressure PSI (kPa) 50(345) 50(345)
Max. Continuous Water
Temperature F(C)
104°(40°) 104°(40°)
* For best water clarity and filter cycle length, restrict
water flow to 50 GPM (189 LPM).
FIGURE 2 – Pressure Drop Curve
V V
CC
KK
V V E E
R R
M M E E
O O
LL
OO
E E
E E R R
K K C C O O L L
M M O O
E E M M O O R R
C C K K
L L O O
V V
E E
A A
R R A A I I
G GEE U U
L L R R E E A A E E S S E E
P P S SSS U U E E R R G G R REE
RELEASER E L E A S E
19"
(483 mm)
23"
(584 mm)
2158 1295
Model Descriptions
