User’s Manual
Specifications
General (
SyncMaster 152S)
General
Model Name SyncMaster 152 S
LCD Panel
Size 15.0 inch diagonal
Display area 304.1 (H) x 228.1 (V)
Pixel Pitch 0.297 (H) x 0.297 (V)
Type a-si TFT active matrix
Viewing Angle 70/70/55/60(L/R/T/B)
Synchronization
Horizontal 30 ~ 61 kHz
Vertical 56 ~ 75 Hz
Display Color
16, 294,277 Colors
Resolution
Optimum resolution 1024 x 768@60Hz
Maximum resolution 1024 x 768@75Hz
Input Signal, Terminated
RGB Analog, 0.7 Vpp positive at 75 ohms Separate H/V sync,
TTL level positive or negative
Maximum Pixel Clock
80 MHz
Power Supply
AC 90 ~ 264 VAC, 60/50 Hz ± 3Hz
Signal Cable
15pin-to-15pin D-sub cable, detachable
Power Consumption
Max. 3 5W
Dimensions (WxDxH)
357.5 X 184.5 X 361.6mm (After installing of Stand)
357.5 X 50.7 X 288.5mm (After folding the stand)
Weight
2.9kg (With Bagic Stand)
3.1kg (Multimedia Stand)
VESA Mounting Interface
75mm x 75mm (for use with Specialty(Arm) Mounting hardware.)
