User’s Manual

Setup

Connecting Your Monitor

(SyncMaster 152B/152S)

Setup-General

1. Connect the DC Adapter for your monitor to the power port on the back of the monitor. Plug the

power cord for the monitor into a nearby outlet.

2. Connect the signal cable to the 15-pin, D-sub connector on the back of your monitor.

3. Connect the monitor to the Macintosh computer using the D-SUB connection cable.

4. In the case of an old model Macintosh, you need to connect the monitor using a special Mac

adaptor.

5. Turn on your computer and monitor. If your monitor displays an image, installation is complete.
