CONTENTS
PRECAUTIONS..................................................................................... 2
PARTS NAMES..................................................................................... 3
CONCERNING AUTO-IRIS LENSES ...................................................... 5
MOUNTING THE LENS ........................................................................ 6
CONNECTIONS .................................................................................... 8
SETTINGS............................................................................................. 9
TROUBLESHOOTING........................................................................... 11
SPECIFICATIONS.................................................................................. 12
ACCESSORIES ...................................................................................... 13
Depending on the conditions of use, installation and environment,
please be sure to make the appropriate settings and adjustments. If
you need help with installation and/or settings, please consult your
dealer.
FEATURES
• Infrared signals immediate area sensitivity is improved by about 10
dB from previous models.
• Built-in interline transfer method 1/2" CCD, approx. 470,000
picture elements
• Low smear, anti-blooming, low lag, no burning and no geometric
distortion using the CCD solid state image device.
• 100% solid state components giving excellent immunity to shock
and vibration
• Not subject to interference from magnetic or electrostatic fields
• High sensitivity, minimum required illumination of 0,02 lux with
F1.2 lens
• Horizontal resolution, more than 560 TV lines
• New backlight compensation function (Active when using an
auto-iris lens)
• Externally adjustable flange back (mechanical focus)
• Low power consumption and quick start
• 12 V DC operation
