5
Or connect the window kit adaptor to the external end of the exhaust duct for a window
or sliding door hot air outlet installation.
c)
NOTE: In order to increase the efficiency, the exhaust duct should be keep as short and
straight as possible. The exhaust hose can be cut shorter by unthreading either end of the
exhaust duct counter clockwise. It is not recommended to increase the manufacturer’s length
of the exhaust hose. This may impede or damage the unit.
Window Kit Installation
Open window or sliding door for approximately 5 inches (130 mm).
Adjust the length of the window kit to the same length of the window or the sliding door.
Use all three panels if necessary.
Use screws to affix the window kit length.
Place the window kit to the window or sliding door. Close the window or door as far as
it goes.
Mount the window kit extension of the exhaust host onto the window kit.
Use screws on the window kit extension if necessary.
a)
b)
c)
d)
e)
f)
NOTE: When using the window kit on a window or sliding door it will cause the window or
sliding door not to be properly closed and locked. Additional security measurements should be
taken.
windows
exhaust air opening
