3
PACKAGE CONTAINS:
Mobile Air Conditioner
Air Exhaust Duct
Exhaust Duct Window Kit Adapter
Romote Controller
LITHIUM BATTERY 3V –
Window Kit - 3 Sliding Panels
Window Kit Fastener Screws (4)
User Manual
NAMES OF PARTS
F R O N T
B A C K
h o t a i r o u t l e t g r i l l
lower air inlet grill
u p p e r a i r
inlet grill
O u t l e t f o r C o n t i n u o u s D r a i n a g e
Use exclusively for continuous
d r a i n a g e .
Don't pull out the outlet except
f o r t h i s a p p l i c a t i o n . O t h e r w i s e
t h e d r a i n w i l l l e a k .
control panel
a i r f l o w g u i d e r
swing louver
front air outlet grill
castol
handle
water tank
c a b l e ( p o w e r
c o r d a n d p l u g )
