4
Exhaust Duct
Window Kits
Exhaust Duct
When you use the unit as an air conditioner, the hot exhaust air must be directed out of the
room. The exhaust duct is used to allow the hot air out. DO NOT INSTALL OR USE THE
EXHAUST DUCT WHEN THE UNIT IS OPERATED AS A DEHUMIDIFIER OR FAN.
Slide exhaust connector all the
over the hot Air outlet grill.
Mount the external and of the ex-
haust duct onto a bole of 5 1 /
4
" (132
mm) on the wall for optional wall
hot air outlet installation.
a)
b)
Unit Terminal End
Exhaust Duct
Window Kit Adaptor
