68
2008 F-250/F-350/F-450
Super Duty ® Pickups
F-250/F-350/F-450 SD PICKUPS
July 2007
F-250/F-350/F-450
SD Pickups
F-450 DRW Styleside Pickup
DRIVE: 4x2 4x4
POWERTRAIN: Refer To The Ordering Guide For 50 States Usage
Engine (1) — Type 6.4L (390.5 CID) OHV V-8
Transmission — Type Heavy-Duty Manual
— Speeds 6-Speed Overdrive
Clutch Diameter 13”
Transfer Case — Type — Part-Time, 2-Speed
— Low/High Gear Ratio — 2.72:1/1.00:1
AXLES:
Front Axle — Type Twin I-Beam IFS, Ford Monobeam, Dana 60
— Capacity (Rating @ Ground) 7000 lbs.
— Hubs Type — Manual Locking
Rear Axle — Type—Full-Floating Visteon
— Capacity (Rating @ Ground) 11000 lbs.
BRAKES:
Front/Rear Disc — Type Dual-Piston Pin-Slider Calipers, Bolt-on Adapters, Wrap-around Tie Bars
— Rotor Diameter—Front/Rear 14.53/15.35 ″
Power Assist Unit — Type Hydro Boost
— Effective Diameter 1.56” Power Piston
Anti-Lock System 4-Wheel (3-Channel)
Parking Brake (Rear Brakes) 8.1 ″ Drum-In-Hat (Foot-Operated, Hand Release)
ELECTRICAL:
Alternator — Rating 135 Amperes, 2025 Watt
Battery — Type Maintenance-Free
— Rating Dual 78 Amp-hr., 750 CCA
Harnesses — Type Trailer 7/4-Wire Harness And Connector/Trailer Brake Wiring/Feed Kit (In-cab,
No Controller)
FUEL TANK: — Capacity 38.0 Gal. (143 L)
JACK: — Capacity 6 Ton
STEERING: — Type Power, Ford XR-50 (Includes Steering Damper)
— Ratio 17.0:1
SUSPENSION:
Frame — Type Ladder Type, 36,000 psi Steel
— Section Modulus (cu. in.) 6.7
Springs, Front — Type Coil, Computer Selected
— Rating @ Ground (min.) Refer to page 64 for usage and ratings
Springs, Rear — Type Leaf, Two-Stage Variable Rate Main and Single-Stage, Constant Rate Auxiliary
— Rating @ Ground (min.) Refer to page 64 for usage and ratings
Shock Absorbers — Gas-Type 1.38 ″
Stabilizer Bar Front and Rear
TIRES: — Type Steel-Belted Radial, All-Season, BSW
— Size Seven, 225/70Rx19.5F
— Spare Tire Carrier Rear Underframe, Crank Down Type (Includes Lock)
WHEELS: — Type and Size Seven, 10-Hole Disc, 19.5 ″ x 6″J Steel
(1) In addition to the content shown above, 6.4L V-8 Diesel includes fuel-line filter, heater and water separator, integral engine oil cooler, vacuum
pump, tachometer and turbo boost gauge and Wait To Start,” “Water-In-Fuel,” “Fuel Filter” and “Air Filter” indicator lights.
NOTE: Refer to page 64 for Standard and Optional Weight Rating Specifications (GVWR/Payload/Spring & GAWR/Base Curb Weight).
Standard Powertrain/Chassis
Equipment Specifications cont’d
