62
2008 F-250/F-350/F-450
Super Duty ® Pickups
F-250/F-350/F-450 SD PICKUPS
July 2007
F-250/F-350/F-450
SD Pickups
NOTE: Refer to page 66 for Standard Powertrain/Chassis Equipment Specifications. Refer to pages 79–80 for optional equipment weights.
NOTE: The standard front spring/GAWR on Pickup models is computer-selected based on the total front weight of options ordered. Front spring/
GAWR upgrades are in increments of 150 lbs. on 4x2 models with spring ratings from 3650 lbs. to 4850 lbs. and in increments of 400 lbs. on
4x4 models with spring ratings from 4000 lbs. to 6000 lbs. Certain option packages include the following front spring/GAWR upgrades: Heavy
Service Suspension Package, Heavy Service Package For Pickup Box Delete and Stabilizer Package - Front springs/GAWR will be selected 1
upgrade higher than standard computer selection; Camper Package - Front springs/GAWR will be selected 2 upgrades higher than standard
computer selection on 4x2 models and 1 upgrade higher than standard computer selection on 4x4 models; Snowplow Package - Front springs/
GAWR is assigned or specifically selected as shown in the chart above. Front spring/GAWR upgrade is not included if the maximum front spring
has been computer-selected as a consequence of options ordered.
F-350 SRW Styleside Pickup/Pickup Box Delete (1) with 18”/20” Tires/Wheels-
GVWR/Payload/ARC/Spring & GAWR (Front Computer-Selected Except with
Snowplow)/Base Curb Weight
(1) Pickup box delete available with Regular Cab 137 ″ WB, SuperCab 158 ″ WB and Crew Cab 172.4 ″ WB models with 5.4L or 6.4L engines
only. Base Curb Weights shown above are for completed pickup truck models with standard equipment and the engine/transmission
combination indicated. To adjust the “Base Curb Weight” to reflect Pickup Box Delete add 54 lbs. to the “Front” weight and subtract 550 lbs.
from the “Total” weight (adjust the “Rear” weight by subtracting “Front” from “Total”). This provides the weight effect of deleting the pickup
box, rear step bumper and standard spare tire, wheel and carrier. Please also refer to footnote 3.
Cab
Style/
Drive/WB
(in.)
Engine/
Transmission
Maximum
GVWR (lbs.)
Std./Opt.
Maximum
Payload
(lbs.) (2)
Std./Opt.
(2) Load rating represents maximum allowable weight of people, cargo and body equipment and is reduced by optional equipment weight.
OPT/
ARC
Weight
(lbs.) (3)
(3) OPT/ARC Weight is the maximum allowable weight for regular production options (OPT) and aftermarket equipment (Accessory Reserve
Capacity) for completed pickup truck models with standard equipment and the powertrain combination indicated. To adjust the OPT/ARC
weights to reflect Pickup Box Delete add 550 lbs. Please also refer to footnote 1.
Spring/GAWR (lbs.) (4)
(4) Gross Axle Weight Rating is determined by the rated capacity of the minimum component of the axle system (axle, computer-selected springs,
wheels, tires) of a specific vehicle. Front and rear GAWRs will, in all cases, sum to a number equal to or greater than the GVWR for the
particular vehicle. Maximum loaded vehicle (including passengers, equipment and payload) cannot exceed the GVW rating or GAWR (front
or rear).
Base Curb Weight
(lbs.)
Front
Range
Min.-Max.
Front
Snow-
plow Rear (5)
(5) 7000/6390 rear spring/GAWR with optional 10,000 lb. GVWR.
Front Rear Total
Regular
Cab
4x2 - 137
5.4L/Manual 10,100/10,000 4220/4120 454 3650-4250 — 7000/6300 3230 2583 5813
6.8L/Manual 10,100/10,000 4090/3990 408 3800-4400 — 7000/6300 3386 2562 5948
6.4L/Manual 10,700/10,000 3860/3270 399 4250-4850 — 7000/6693 4062 2701 6763
Regular
Cab
4x4 - 137
5.4L/Manual 10,500/10,000 4160/3770 520 4000-5600 5200 7000 3635 2638 6273
6.8L/Manual 10,700/10,000 4220/3630 479 4400-5600 5200 7000 3794 2614 6408
6.4L/Manual 11,100/10,000 3800/2810 460 4800-6000 6000 7000 4459 2764 7223
SuperCab
4x2 -
141.8
5.4L/Manual 10,100/10,000 3970/3870 447 3650-4400 — 7000/6300 3329 2734 6063
6.8L/Manual 10,300/10,000 4040/3740 423 3800-4400 — 7000/6300 3468 2730 6198
6.4L/Manual 10,800/10,000 3710/3020 412 4250-4850 — 7000/6693 4160 2853 7013
SuperCab
4x2 - 158
5.4L/Manual 10,400/10,000 4150/3850 503 3950-4700 — 7000/6693 3425 2763 6188
6.8L/Manual 10,600/10,000 4210/3710 466 4100-4700 — 7000/6693 3562 2761 6323
6.4L/Manual 11,000/10,000 3790/2890 426 4550-4850 — 7000/6693 4261 2877 7138
SuperCab
4x4 -
141.8
5.4L/Manual 10,600/10,000 4010/3510 506 4400-5600 5200 7000 3731 2792 6523
6.8L/Manual 10,800/10,000 4070/3380 466 4400-5600 5200 7000 3885 2773 6658
6.4L/Manual 11,200/10,000 3650/2550 468 4800-6000 6000 7000 4550 2923 7473
SuperCab
4x4 - 158
5.4L/Manual 10,800/10,000 4080/3390 599 4400-5600 5600 7000 3839 2809 6648
6.8L/Manual 11,000/10,000 4140/3250 498 4800-5600 5600 7000 4000 2783 6783
6.4L/Manual 11,400/10,000 3720/2430 485 5200-6000 6000 7000 4666 2932 7598
Crew Cab
4x2 -
156.2
5.4L/Manual 10,400/10,000 4090/3800 640 3800-4550 — 7000/6693 3427 2811 6238
6.8L/Manual 10,600/10,000 4160/3660 609 3950-4700 — 7000/6693 3569 2804 6373
6.4L/Manual 11,000/10,000 3740/2840 590 4400-4850 — 7000/6693 4260 2928 7188
Crew Cab
4x2 -
172.4
5.4L/Manual 10,600/10,000 4170/3670 690 4100-4850 — 7000/6693 3534 2829 6363
6.8L/Manual 10,800/10,000 4230/3540 645 4250-4850 — 7000/6693 3680 2818 6498
6.4L/Manual 11,200/10,000 3810/2710 625 4700-4850 — 7000/6693 4357 2956 7313
Crew Cab
4x4 -
156.2
5.4L/Manual 10,800/10,000 4030/3340 707 4400-5600 5600 7000 3842 2856 6698
6.8L/Manual 11,000/10,000 4090/3200 642 4400-5600 5600 7000 (6)
(6) 7000/6900 rear spring/GAWR with optional LT275/65R20E tires.
3994 2839 6833
6.4L/Manual 11,400/10,000 3670/2380 650 4800-6000 6000 7000 4660 2988 7648
Crew Cab
4x4 -
172.4
5.4L/Manual 11,000/10,000 4100/3210 761 4800-6000 5600 7000 3945 2878 6823
6.8L/Manual 11,200/10,000 4170/3070 693 4800-6000 5600 7000 4097 2861 6958
6.4L/Manual 11,500/10,000 3640/2250 682 5200-6000 6000 7000 (6) 4765 3008 7773
Weight Ratings cont’d
