2008 F-250/F-350/F-450
Super Duty ® Pickups
61
F-250/F-350/F-450 SD PICKUPS
July 2007
F-250/F-350/F-450
SD Pickups
NOTE: Refer to page 66 for Standard Powertrain/Chassis Equipment Specifications. Refer to pages 79–80 for optional equipment weights.
NOTE: The standard front spring/GAWR on Pickup models is computer-selected based on the total front weight of options ordered. Front spring/
GAWR upgrades are in increments of 150 lbs. on 4x2 models with spring ratings from 3650 lbs. to 4850 lbs. and in increments of 400 lbs. on
4x4 models with spring ratings from 4000 lbs. to 6000 lbs. Certain option packages include the following front spring/GAWR upgrades: Heavy
Service Suspension Package, Heavy Service Package For Pickup Box Delete and Stabilizer Package - Front springs/GAWR will be selected 1
upgrade higher than standard computer selection; Camper Package - Front springs/GAWR will be selected 2 upgrades higher than standard
computer selection on 4x2 models and 1 upgrade higher than standard computer selection on 4x4 models; Snowplow Package - Front springs/
GAWR is assigned or specifically selected as shown in the chart above. Front spring/GAWR upgrade is not included if the maximum front spring
has been computer-selected as a consequence of options ordered.
F-350 SRW Styleside Pickup/Pickup Box Delete (1) with 17" Tires/Wheels —
GVWR/Payload/ARC/Spring & GAWR (Front Computer-Selected Except with
Snowplow)/Base Curb Weight
(1) Pickup box delete available with Regular Cab 137" WB, SuperCab 158" WB and Crew Cab 172.4" WB models with 5.4L or 6.4L engines
only. Base Curb Weights shown above are for completed pickup truck models with standard equipment and the engine/transmission
combination indicated. To adjust the “Base Curb Weight” to reflect Pickup Box Delete add 54 lbs. to the “Front” weight and subtract 550 lbs.
from the “Total” weight (adjust the “Rear” weight by subtracting “Front” from “Total”). This provides the weight effect of deleting the pickup
box, rear step bumper and standard spare tire, wheel and carrier. Please also refer to footnote 3.
Cab
Style/
Drive/
WB (in.)
Engine/
Transmission
Maximum
GVWR (lbs.)
Std./Opt.
Maximum
Payload
(lbs.) (2)
Std./Opt.
(2) Load rating represents maximum allowable weight of people, cargo and body equipment and is reduced by optional equipment weight.
OPT/
ARC
Weight
(lbs.) (3)
(3) OPT/ARC Weight is the maximum allowable weight for regular production options (OPT) and aftermarket equipment (Accessory Reserve
Capacity) for completed pickup truck models with standard equipment and the powertrain combination indicated. To adjust the OPT/ARC
weights to reflect Pickup Box Delete add 550 lbs. Please also refer to footnote 1.
Spring/GAWR (lbs.) (4)
(4) Gross Axle Weight Rating is determined by the rated capacity of the minimum component of the axle system (axle, computer-selected springs,
wheels, tires) of a specific vehicle. Front and rear GAWRs will, in all cases, sum to a number equal to or greater than the GVWR for the particular
vehicle. Maximum loaded vehicle (including passengers, equipment and payload) cannot exceed the GVW rating or GAWR (front or rear).
Base Curb Weight
(lbs.)
Front
Range
Min.-Max.
Front
Snow-
plow Rear Front Rear Total
Regular
Cab
4x2 - 137
6.4L/Manual 10,200/10,000 3470/3270 444 4100-4700 — 7000/6390 4045 2613 6658
Regular
Cab
4x4 - 137
5.4L/Manual 10,100/10,000 3870/3770 1154 4000-5600 5200 7000/6262 3604 2564 6168
6.8L/Manual 10,200/10,000 3830/3630 513 4400-5600 5200 7000/6262 3739 2564 6303
6.4L/Manual 10,600/10,000 3410/2810 494 4800-6000 6000 7000/6262 4439 2679 7118
SuperCab
4x2 -
141.8
6.4L/Manual 10,400/10,000 3420/3020 456 4250-4850 — 7000/6262 4146 2762 6908
SuperCab
4x2 - 158
5.4L/Manual 10,100/10,000 3950/3850 1145 3950-4550 — 7000/6262 3400 2683 6083
6.8L/Manual 10,200/10,000 3910/3710 508 4100-4700 — 7000/6262 3537 2681 6218
6.4L/Manual 10,600/10,000 3490/2890 469 4550-4850 — 7000/6262 4242 2791 7033
SuperCab
4x4 -
141.8
5.4L/Manual 10,200/10,000 3710/3510 539 4000-5600 5200 7000/6262 3699 2714 6418
6.8L/Manual 10,400/10,000 3780/3380 499 4400-5600 5200 7000/6262 3836 2717 6553
6.4L/Manual 10,800/10,000 3350/2750 500 4800-6000 6000 7000/6262 4540 2828 7368
SuperCab
4x4 - 158
5.4L/Manual 10,400/10,000 3790/3390 597 4400-5600 5600 7000/6262 3815 2728 6543
6.8L/Manual 10,600/10,000 3850/3250 529 4800-5600 5600 7000/6262 3958 2720 6678
6.4L/Manual 11,000/10,000 3430/2430 517 5200-6000 6000 7000/6262 4645 2848 7493
Crew Cab
4x2 -
156.2
5.4L/Manual 10,100/10,000 3900/3800 1282 3800-4550 — 7000/6262 3397 2736 6133
6.8L/Manual 10,200/10,000 3860/3660 651 3950-4700 — 7000/6262 3530 2738 6268
6.4L/Manual 10,600/10,000 3440/2840 632 4400-4850 — 7000/6262 4253 2830 7083
Crew Cab
4x2 -
172.4
5.4L/Manual 10,200/10,000 3870/3670 730 4100-4850 — 7000/6262 3506 2752 6258
6.8L/Manual 10,400/10,000 3940/3540 685 4250-4850 — 7000/6262 3640 2753 6393
6.4L/Manual 10,800/10,000 3510/2010 666 4700-4850 — 7000/6262 4344 2864 7208
Crew Cab
4x4 -
156.2
5.4L/Manual 10,400/10,000 3740/3340 738 4400-5600 5600 7000/6262 3808 2785 6593
6.8L/Manual 10,600/10,000 3800/3200 673 4400-5600 5600 7000/6262 3941 2787 6728
6.4L/Manual 11,000/10,000 3380/2380 681 4800-6000 6000 7000/6262 4659 2884 7543
Crew Cab
4x4 -
172.4
5.4L/Manual 10,600/10,000 3810/3210 791 4800-5600 5600 7000/6262 3924 2794 6718
6.8L/Manual 10,800/10,000 3870/3070 723 4800-5600 5600 7000/6262 4050 2803 6853
6.4L/Manual 11,200/10,000 3450/2250 712 5200-6000 6000 7000/6262 4756 2912 7668
Weight Ratings cont’d
