PAGE 54 ZIPPIE GS
90 DEGREE LIFT-OFF HANGER
NOTE: THIS HANGER HAS BEEN TESTED AND APPROVED FOR OCCUPANTS THAT WEIGH LESS THAN 150 POUNDS.
Pos. Item Number Description Remarks
1 226198 5/16 -18 x 2 BH C/S SHT THREAD
3 201100-QU 1/4-28 NYLOCK NUT THIN
4 561002 1" INSERT PLUG .083
5 561197 PLASTIC PIVOT SADDLE
6 202103 5/16-18 NYLOCK NUT THICK
7 880053 FOOTREST BLOCK T45
8 202102 5/16-18 NYLOCK NUT THIN
9 321141 .650L x 6 COIL SPRING
10 560684 T45 FOOTREST BLOCK RECESSED
11 226194 5/16-18 x 1.63 BH C/S
12 221100-QU 1/4-28 x 3/4 HEX C/S
7-11 920720 FOOTREST BLOCK ASSM W/BOLT HD
1-6,12 885005 90ø F/D H/D L/O HNGR ASSM PNTD
