R E S I D E N T I A L

© 2007 State Industries, Inc.

For more information on Select

®

contact:

State Water Heaters

500 Tennessee Waltz Parkway, Ashland City, TN 37015

800-365-0024 Toll-free USA

www.statewaterheaters.com

SRGSS01206

*Location for optional top-mounted T&P Valve,

if ordered from factory. To order, add “G” to model
number (GS6 40 YBRT G)

.

Flammable Vapor Ignition Resistant C3 Technology Water Heaters

®

Corderite Combustion Containment (C3) design meets American National Standards Institute

standards (ANS Z21.10.1-CSA 4.1) that deal with the accidental or unintended ignition of flammable

vapors, such as those emitted by gasoline.

Covered by four U.S. patents, C3 Technology gas water heaters feature a sealed combustion chamber

with air intake screen and a fireproof Corderite flame arrestor built into the water heater base. In

addition, a Thermal Cutoff (TCO) device, integral with the thermocouple, is designed to shut off gas

flow to the burner and pilot if poor combustion is detected.

In the unlikely event
that flammable vapors
accidentally enter the
combustion chamber,
the Corderite flame
arrestor is designed
so any flames burn off
the top surface and
cannot escape down
through the arrestor.

SELECT

®

A. Easy-to-light
Piezo Ignitor

B. View port for
easy inspection
of burner inside
sealed combustion
chamber

For complete information on limited warranties, consult written warranty,
or contact the State Customer Care Center, 1-800-365-0024.

State Industries, Inc. reserves the right to make product changes or improvements without prior notice.

Residential Gas Water Heaters

Recoveries are rounded to nearest gallon.
Water Connections – 3/4" male on all models except GS6 50 YBRT (3/4" female).
External heat trap nipples are supplied on all models except GS6 50 YBRT.
† Propane Gas – 37,000 BTU models.
**All models are 1-inch foam except GS6 50 YBRS (2-inch foam).

A

B C D E F

TALL MODELS

SHORT MODELS

DIMENSIONS IN INCHES

July 2007R

GS6 30 YBRS 66 0.61 30 40,000 40 8

48-1/8 43-3/4 18-1/2 13-3/8 8 36-5/8 3 or 4 122

GS6 40 YBRS 71 0.59 40 40,000 41 8

51-5/8 47-1/4 20 13-3/8 8 41 3 or 4 139

GS6 50 YBRS 80 0.58 50 40,000 41 16 53-1/4 48-3/4 24 13-3/8 8 43-1/2 3 or 4 168

GS6 30 YBRT 66 0.62 28 40,000 41 8

59-5/8 55-1/4 16 13-3/8 8 49-7/8 3 or 4 112

GS6 40 YBRT 71 0.59 38 40,000 39

57-5/8 53-1/4 18-1/2 13-3/8 8 47-3/8 3 or 4 126

GS6 50 YBRT 91 0.58 50 40,000 41

60-7/8 56-1/2 20 13-3/8 8 50-3/8 3 or 4 160

MODEL

NUMBER

ENERGY
FACTOR

GALLON

CAPACITY

BTU INPUT

PER HOUR

NATURAL†

RECOVERY

90 F RISE

GALLONS

R

VALUE

DRAFT

HOOD

OUTLET

APPROX.

SHIPPING

WEIGHT

(LBS)

PEAK

DEMAND

OUTPUT

(1st Hour

Rating

Gallons)

For 10-Year Tank and 6-Year Parts Warranty, change " 6" to "X" in Model Number (GS X 40 YBRT).
When ordering Propane, change "Y" to "H" in model number (GS6 40 HBRT).
When ordering top-mounted T&P Valve, add "G" to model number (GS6 40 YBRT G).

ANODE ROD

*

COLD

CONNECTION

HOT

CONNECTION

T&P VALVE

1/2” GAS

CONNECTION

D

A

B

F

C

E

8

8

53-1/4

13-3/8

13-3/8

47-3/8

3 or 4

112

126

160

122

139

168

24

47-1/4

48-3/4

53-1/4

57-5/8

13-3/8

48-1/8

8

8

8

8

8

8

8

8

16

40

41

41

40,000

40,000

40,000

40,000

40,000

40,000

179681 New SRGSS01206 2
