OPERATING INSTRUCTIONS cont.

OPERATING INSTRUCTIONS

Using The Unit With Air
Driven Turbo Brush

Fig. 5

Debris

Screen

HEPA Filter

Cleaning & Changing the
HEPA Dust Cup Filter

Warning:

Always unplug the unit

from electrical outlet before opening

the Dust Cup (container).

1. To open the Dust Cup (container),

push button and detach the Dust

Cup (container ). (Fig. 2)

2. Pull out the HEPA Dust Cup Filter.

(Fig. 3)

Important:

Do NOT use the HEPA filter

cartridge without the debris screen in

place.

Warning

:

After each Use - Always

remove the Filter Debris Screen

from the HEPA Dust Cup Filter, then

vigorously “TapClean” HEPA Filter until

no more dust can be removed.
IMPORTANT, Please Note : The

“TapClean” HEPA Dust Cup Filter &

Debris Screen will stop most of the tiniest

dust particles and airborne allergens from

re-entering the air you breathe. In fact it

stops 99.97% of all particles as small as

0.3 microns - many times smaller than a

human hair!!! Because of this incredible

filtration performance, the HEPA Dust Cup

Filter will quickly accumulate, inside the

white filter folds, many fine dust particles

that are difficult to see but which will

eventually block or reduce your suction

power - if not cleaned properly. Clean the

HEPA Filter and Debris Screen after each

use as described in this section.

3. Empty the dust from

the Dust Cup

(container). (Fig. 4)

4. Separate the debris

screen from the

HEPA filter cartridge

by grasping the

debris screen with

one hand and the filter frame with the

other and pull apart. (Fig. 5)

Fig. 3

Fig. 2

Fig. 4

Warning: Always unplug from

electrical outlet before opening the

dust cup (container).
Note: HEPA dust cup filter must be used

when operating the hand vacuum.

Using The Unit As A Hand
Vacuum

1. To open the dust

cup (container),

push the dust cup

release button and

pull out the dust

cup. Verify that the

HEPA dust cup filter is inside

(see illustration below), then re-

attach the dust cup (container) to

the hand vacuum.

2. To use the Hand Vacuum with the

shoulder strap, attach it to the unit as

shown below.

How To Operate Your

Hand Vacuum

1. Hold the hand vacuum firmly in your

hand by the Handle.

2. Push the On/Off Power Switch to

“On” position.

3. Start vacuuming.

CAUTION: The Hand Vacuum is

a very powerful unit. Make sure

that you hold it firmly, otherwise it

can slip out of your hand and cause

injury.

4. To use the flexible hose, push

the end of the hose into the

suction hole, then attach the

desired accessory to the other

end of the flexible hose,

as shown below.

NOTE: The pet hair removal

attachment is for use on upholstery,

drapes and other fabric surfaces to

remove lint, pet hair, etc. THE PET

HAIR REMOVAL ATTACHMENT IS

NOT INTENDED TO BE USED AS A

PET GROOMING DEVICE.

3. To attach the oval dusting brush,

crevice brush or the pet hair

removal attachment to the Hand

Vacuum, push attachment into the

suction hole, as shown below.

Important: This unit is equipped with a

motor protective thermostat. If for some

reason the vacuum cleaner should

overheat, the thermostat will

automatically turn the unit off. Should

this occur:

• Push the On/Off button once.

• Disconnect the plug from the

power source.

• Check the source of overheating

problem. (i.e. clogged hose or

filter)

• If clogged hose or filter is found,

unclog the hose and replace the

filters.

• Wait at least 45 minutes before

attempting to reuse the vacuum.

• After unit has cooled down for

45 minutes, plug in the cleaner

and push the On/Off button. The

vacuum should start again.

• If the vacuum still does not start,

contact customer service at

1 (800) 798-7398.

The efficiency of your air driven turbo

brush depends on the bristle brush

rotating at high speed. Strong air suction

is needed to accomplish this. In order to

ensure that maximum air suction is

maintained, please read the following

instructions:
1. Empty the dust cup frequently.

2. Always "TAPCLEAN" the HEPA dust

cup filter when emptying the dust cup

container.

3. Ensure that the rotating brush is kept

free of hair and string which may

accumulate and decrease brush

performance.

4. Keep Air Driven Turbo Brush turbine

free of dirt and foreign matter. (See

illustration below for cleaning

instructions.)

Cleaning Air Driven Turbo
Brush

Turbine

Wheel

Tilt

Upwards

Locking

Latch

Fig. 1

From time to time, the turbine of your

turbo brush will require cleaning. To do

this:

1. Remove the turbo brush from the hose

or unit.

2. Turn turbo brush over and open the

hinged cover to access the turbine

wheel. (see Fig. 1)

3. There may be some dust, lint, hair, etc

on the turbine wheel. Remove as much

of this as possible.

4. You may also use the unit’s hose to

remove any additional debris from the

turbine.
