Scag Power Equipment MODEL TS - Manual (Page 11)

9
TIGER STRIPER ASSEMBLY - STC
Ref. Part
No. Number Description
1 423966 Spacer, Striper Mounting
2 43653 Roller Shaft
3 48100-24 Bushing, .752 Oilite
4 04100-01 U-Bolt, 5/16-18 x 1"
5 451660 Mounting Bracket Weldment, LH. **L.H. Mounting Bracket is used on the Right Side on STC
6 04041-11 Flatwasher, 3/8-.406 x 1-1/2" 7 Gauge
7 04001-22 Bolt, Hex Head 3/8-16 x 2-3/4"
8 04019-04 Nut, Serrated Flange 3/8-16
9 04050-02 Retaining Ring, .750 External "E"
10 461777 Pin, Lift Latch
11 04060-01 Pin, Slotted Spring .156 x 3/4"
12 482896 Spring, Lock Pin
13 04001-31 Bolt, Hex Head 3/8-16 x 2-1/2"
14 482894 Spring, Torsion L.H.
15 04019-03 Nut, Serrated Flange 5/16-18
16 04066-02 Quick Pin, .188 Dia.
17 451661 Mounting Bracket Weldment, R.H. **R.H. Mounting Bracket is used on the Left Side on STC
18 482895 Spring, Torsion R.H.
19 43648 Hub, Striper
20 451669 Pivot Weldment, L.H.
21 451670 Pivot Weldment, R.H.
22 451667 Hinge Weldment, R.H.
23 04012-06 Set Screw, 3/8-16 x 1/2"
24 04021-09 Nut, Elastic Stop 3/8-16
25 461707 Roller Assembly (Incl. Item 3)
26 461730 Roller Assembly, Striper End (Incl. Item 3)
27 451668 Hinge Weldment, L.H.
