For Additional Technical Information,
PHONE 800-365-0024
STATE WATER HEATERS
500 Tennessee Waltz Parkway, Ashland City, TN 37015
www.statewaterheaters.com
Page 2 of 2
F
E
C
D
6' POWER CORD
FACTORY
SUPPLIED
B A
1/2" GAS
CONNECTION
3/4" MALE WATER
CONNECTIONS
ON 40 AND 50
GALLON MODELS
AND 1" MALE
ON 74 GALLON Venting Distance:
PR6 40 XCVIT, PR6 50 XCVIT, PR6 40 XCVIT 2, & PR6 50 XCVIT 2
models may be vented using 2" or 3" vent.
- 2" up to 30 feet with one elbow.
- 3" up to 75 feet with one elbow.
PR6 50 XCVIT 5 may be vented using 2", 3" or 4" vent.
- 2" up to 30 feet with one elbow.
- 3" up to 65 feet with one elbow.
- 4" up to 90 feet with one elbow.
GS6 75 YRVIT may be vented using 3" or 4" vent.
- 3" up to 25 feet with one elbow.
- 4" up to 92 feet with one elbow.
S
ELECT ®
POWER-VENT
Residential Gas Water Heaters
6-Year Tank Warranty • 6-Year Parts Warranty
IMPORTANT: VENTING AND COMBUSTION AIR REQUIREMENTS
Read and follow requirements shown in the Installation Manual for Select
Power-Vent Gas water heaters dealing with type, placement and length of
vent pipe and vent termination, as well as clearances required to provide
adequate combustion air and proper ventilation.
For complete information on limited warranties, consult written warranty,
or contact the State Customer Care Center 1-800-365-0024.
State Industries, Inc. reserves the right to make product changes or improvements without prior notice.
SRGSS00905 REV1
SWHR-112336-2.5M-MSI-010206 © 2006 State Industries, Inc. Printed in U.S.A.
FIRST
HOUR
RATING
GALLONS
ENERGY
FACTOR GAL.
CAP.
BTU INPUT
PER HOUR
NATURAL
APPROX.
SHIPPING
WEIGHT
(LBS.)
MODEL
NUMBER
RECOVERY
90°F RISE
GALLONS
PER HOUR
R
VALUE
† Height to top of blower outlet.
79
89
79
89
103
N/A
PR6 40 XCVIT
PR6 50 XCVIT
PR6 40 XCVIT 2
PR6 50 XCVIT 2
PR6 50 XCVIT 5
GS6 75 YRVIT
DIMENSIONS IN INCHES
A† B C D E F
.62
.62
.64
.64
.62
N/A
40
50
40
50
50
74
40,000
40,000
40,000
40,000
65,000
80,000
41
41
41
41
66
86
8
8
16
16
16
12
63-1/2
65
63-1/2
65
69
66
55
56-1/2
55
56-1/2
56-1/2
57
18-1/4
20-1/4
20-1/4
22-1/4
22
25-1/2
13
13
13
13
13
15
8
8
8
8
8
16
48-1/2
49-3/4
48-1/2
49-3/4
49-1/8
50-1/4
2 or 3
2 or 3
2 or 3
2 or 3
2, 3 or 4
3 or 4
155
195
155
195
195
240
VENT
OUTLET
