Spalding 211014 User Manual
Page 12

12
P/N 211014
03/05
SECTION B: ASSEMBLE THE BASE
This is what your system will look like when you’ve
finished this section.
1.
Insert axle (P-5) through wheel bracket (P-4). Secure wheels (P-28) to axle using pushnuts (H-1).
Carefully tap pushnuts (H-1) onto axle with hammer or mallet.
P-4
P-28
P-28
H-1
H-1
P-5
TO INSTALL SECOND
PUSHNUT:
• Assemble Pushnut,
Wheels, Axle, And Wheel
Bracket As Shown.
• Support Pushnut/Axle
From The End With A
Block Of Wood To Install
The Second Pushnut Onto
The Axle.
NOTE:
Wood Block
