7
Connecting the Interface Cable
Connect the parallel or USB interface cable as shown in the figure 2-8 below:
Caution
Make sure that the power switches of both printer and host computer are turned OFF before you
connect the parallel interface cable.
Using the Parallel Interface and the USB Interface
Figure 2-8 Connecting the parallel interface cable and the USB interface cable
Connecting to the Power Source
Connecting the Power Cord
Plug the power cord (supplied) into the power inlet at the rear of the printer.
Check that the power switch (located on the left of the printer) is in the OFF position, then plug the
power cord into the wall outlet.
The parallel interface
Parallel interface
connector
Parallel interface
cable
Figure 2-9 Connecting the power cord to the printer
Power switch
Power supply inlet
Power cord
The USB interface
USB interface
connector
USB interface
cable
