SK 100 G2 / SK 300 G2 / SK 500 G2 bodypack transmitters
SK 100 G2 / SK 300 G2 / SK 500 G2
bodypack transmitters
Delivery includes
The packaging contains the following items:
y
1 bodypack transmitter
y
2 batteries
y
1 BPP 1 bodypack pouch
y
1 clip-on microphone (please specify when ordering)
Operating Controls
³
Microphone/line input (MIC/LINE), 3.5 mm jack socket
·
Antenna
»
Red LED for operation and battery status indication (ON/LOW
BAT)
¿
Yellow LED for audio peak (AF PEAK)
´
Charging contacts
² SET
button
¶
̄
/
̆
rocker button (UP/DOWN)
º
Battery compartment
¾
Battery compartment cover
µ
Unlocking button
¸ ON
/
OFF
button (serves as ESC (cancel) key in the operating
menu)
¹
LC display
Ƹ MUTE
switch
Preparing for use
Inserting and changing the battery
For powering the transmitter, two 1.5 V AA size batteries are
required.
³
·
»
¿
²
´
¸
¹
º
¾
¶
·
Ƹ
µ
