16
5. Remote Control Unit Installation Position
The remote control unit can be operated from either a
non-fixed position or a wall-mounted position.
To ensure that the air conditioner operates correctly, do
not install the remote control unit in the following places:
● In direct sunlight
● Behind a curtain or other place where it is covered
● More than 26 ft. (8 m) away from the air conditioner
● In the path of the air conditioner’s airstream
● Where it may become extremely hot or cold
● Where it may be subject to electrical or magnetic
interference
5-1. Mounting on a Wall
1) Confirm the indoor unit beeps when the ON/OFF
button is pressed at the wall location where the
remote control unit is to be attached, then attach the
holder to the wall. (Fig. 38)
2) When taking out the remote control unit, pull it
from the holder.
When using the remote control unit
• Point the transmission portion of the remote con-
trol unit at the receiver area of the indoor unit
when operating the remote control unit, and dur-
ing operation of the air conditioner.
• Do not place objects that may block the transmit-
ted signals between the receiver and the remote
control unit.
When mounting the remote control unit to
prevent theft
1) Mount the holder to the wall with one of the
screws (using only the hole in the top of the
holder) (Fig. 39).
2) Remove the cover of the remote control unit and
take out the batteries. Next, place the remote
control unit in the holder.
3) Fasten both the remote control unit and holder to
the wall with the remaining screw (using the hole
in the bottom of the holder).
4) Install the batteries in the remote control unit and
close the cover.
Truss-head
tapping screw
5/32
Ч 5/8" (4 Ч 16mm supplied)
Remote
control
unit holder
Holder
Holder
Truss-head
tapping screw
5/32
Ч 5/8" (4 Ч 16mm supplied)
Fig. 39
Fig. 38
