7
•
PARTS
9.
The Sears service centers offer the following replacement parts for your
battery charger. If you are having trouble with your battery charger, please
contact a qualified service person to diagnose and/or repair your unit. It
is not recommended that the consumer service the internal components
of the battery charger, as improper handling or repair could lead to shock,
electrocution, damage to the charger, or result in fire. As such, please con-
tact 1-800-SEARS-64 for troubleshooting assistance and 1-800-366-PART
for repair or replacement parts.
This section shows an illustration of your battery charger. Use it to become
familiar with the location of all the parts, and what they look like.
Replacement Parts List diehard 71240:
Item
description
Part Number
1
Plastic Top
3799004100
2
Rocker Switch SPST
0499000050
3
Rocker Switch DPDT
0499000053
4
Control Board Assembly
2299001465
5
Handle
3599000262
6
Receptacle, GFCI, 15A
0099000587
7
Circuit Breaker
3999000108
8
Positive (RED) Cable w/clamps
3899001165
9
Negative (BLACK) Cable w/clamps
3899001164
10
Power Cord
90026177
11
Power Board/Heatsink Assembly
2299001467
12
Transformer
93026585
13
Fan Motor
0099000604
14
Hardware Kit
2299001078
15
Wheel
0099000120
16
Handle Grip
0399000018
17
Mounting Foot
1199005112
18
Axle
0099000066
19
Owner’s Manual
0099000539
