43
English
Connecting to a video input terminal
Use the supplied dedicated AV interface cable to connect to a TV.
Connecting to the HDMI terminal
Use a separately sold mini-HDMI cable to connect to a TV.
Supplied dedicated
AV interface cable
To USB/AV terminal
Set the input to
“VIDEO”.
Yellow plug:To Video Input terminal
White plug: To Audio Input (L) terminal
Red plug:
To Audio Input (R) terminal
Mini HDMI cable (optional)
To HDMI terminal
To HDMI terminal on the TV
Set the input to
“HDMI”.
