Sony TA-F5000 - Manual (Page 8)

8 GB
Basic Operations
S
POWER
INPUT SELECTOR BASS TREBLE BALANCE VOLUME
PHONES
–10 +10 –10 +10 LEFT RIGHT 0 10
1 9
2 8
3 7
4 6
5
MD TAPE AUX CD TUNER MM - PHONO - MC
Turn on the programme source you want to listen to.
Turn VOLUME fully counterclockwise (to “0”) to prevent
damaging the speakers with excessive output.
Press POWER to turn on the amplifier.
The POWER indicator changes from red to green.
Set INPUT SELECTOR to the respective programme source.
The indicator for the selected programme source lights up.
Play the programme source.
Adjust the volume level by turning VOLUME.
2, 6 3 4
1
2
3
To listen to a
Record
Radio broadcast
Compact disc
Source connected to AUX
Cassette tape
Mini disc
Turn INPUT SELECTOR to
PHONO MC*/MM*
TUNER
CD
AUX
TAPE
MD
4
5
6
Listening to the Music
* Select MC or MM according to the type of cartridge you are using.
