7.8 Scart connector
- Pin 5 Earth B
- Pin 7 Input B 0.7 Vpp, termination 75
- Pin 9 Earth G
- Pin 11 Input G 0.7 Vpp, termination 75
- Pin 13 Earth R 0.7 Vpp, termination 75
- Pin 15 Input R
- o C (S-VHS) 0.3 Vpp, termination 75
- Pin 17 Video Earth
- Pin 19 Video output 1 Vpp, termination 75
- Pin 20 Video input 1 Vpp, termination 75
- Pin 21 Screen Earth
- or common return
7.9 Video inputs
CVBS 1 BNC connector or SCART connector
1Vpp, 75 Ohm termination, neg. sync.
Chroma levels:
0.286 Vpp, NTSC 4.43,
NTSC 3.58 (burst level)
0.3 Vpp, PAL,
0.3 Vpp, SECAM
CVBS 2 BNC connectors, same levels as CVBS 175
Ohm termination, neg. sync
S-VHS 1 4-pin MINI DIN. connectors Levels: 1 Vpp for Y/
75 signal; 0,3 Vpp for C/75 signal
S-VHS 2 scart connector (Pin 20-Y; Pin 15-C; Pin 17-
Earth)
Input Video width 5.5 MHz-3dB
Standard PAL, SECAM, NTSC 3.58, NTSC 4.43
automatically switched
In case of bad input signal, the video standard can be
forced by means of the remote control.
- C.T.I. always active
- Noise reduction on/off
- Peaking control
- Comb. filter on/off
- Luma/chroma delay adjustment
- NTSC: hue control
7.10 PC control
Through the RS422 interface, the video projector can be
controlled by a PC via a dedicated software.
PC connector: D-sub. 9 Pin
This input is compatible with most computers, such as
IBM VGA, etc...
8 ELECTRICAL DATA
Power consumption: 270W max (6W on stand-by)
Line voltage range: 120-240Vac 50-60Hz
Fuse: T 5 A
9 MECHANICAL DATA
Dimensions:
Width 620 mm
Height 290 mm
Depth 700 mm
Weight:
35 Kg net weight
Packaging:
Reinforced cardboard, filled with anti-shock stuff - 4
handles for transportation
Packaging dimensions:
Width 840 mm
Height 490 mm
Depth 1300 mm
10 TEMPERATURE AND HUMIDITY RANGE
Operation 0 to +35°C
Umidity 0 to 90% no condensation
Immunity In conformity with EN 50082
11 SUPPLIED ACCESSORY
- AC power cables
- Lenses plastic caps
- Lenses spacers
- RC-3000 complete function remote control with
batteries
- RC-3100 remote control with batteries
- Remote control cable (8m)
- Ceiling assembly kit
- Installation and use manual
