Shure LEGENDARY PERFORMANCE SM57 User Manual
Page 11
12
157 mm
(6 3/16 in.)
32 mm
(1 1/4 in.)
23 mm
(29/32 in.)
125 Hz
500 Hz
1000 Hz
2000 Hz
4000 Hz
8000 Hz
OVERALL DIMENSIONS – DIMENSIONS HORS TOUT
GESAMTABMESSUNGEN – DIMENSIONES TOTALES – DIMENSIONI TOTALI -
INTERNAL CONNECTIONS -
TYPICAL FREQUENCY RESPONSE
COURBE DE REPONSE TYPIQUE - TYPISCHES FREQUENZVERHALTEN
RESPUESTA DE FRECUENCIA TIPICA - TIPICA RISPOSTA IN FREQUENZA
TYPICAL POLAR PATTERNS
COURBE DE DIRECTIVITE TYPIQUES - TYPISCHE POLARCHARAKTERISTIK
PATRONES DE CAPTACION POLAR TIPICOS - TIPICI DIAGRAMMI POLARI
