SECO-LARM USA Enforcer Video EVP-1SA4P9UL - Manual

Each output individually fused (PTC**-type fuses).
Output fuses rated 1.1 Amps @ 250VAC.
Individual red LED status indicator for each output.
Main power switch to turn on/off power to outputs
1.949.261.2999 (CA & Int’l) 1.800.662.0800 Fax: 1.949.261.7326
Email: [email protected] Website: www.seco-larm.com
16842 Millikan Avenue, Irvine, CA 92606
AC_PanelPowerSupplyEmail.cdr
Features:
Input: 110VAC, 60Hz. Output: 24VAC.
UL-approved power transformer.
Total output current:
4.0 Amps (EVP-1SA4P4UL, EVP-1SA4P9UL)
8.0 Amps (EVP-1SA8P16UL).
Main fuse rated 5.0 Amps @ 250VAC.
Spare fuse and 6-foot power cord included.
Power
Heavy-duty steel case to protect the power connections.
Removable steel cover for easy access to power connections.
Ventilation holes to prevent heat build-up.
3 1 Dimensions - 10” x 7 /
4
” x 3 /
2
”
Knock-out on the cover for optional cam lock.
AC terminal block for easy connection from transformer to 6-foot
power cord.
Enclosure
®
EVP-1SA4P4UL
4 Outputs @ 24VAC (4 Amps*)
The SECO-LARM policy is one of continual development. For that reason, SECO-LARM reserves the right to change prices and specifications without notice. SECO-LARM is not responsible for misprints.
Copyright 2007 SECO-LARM U.S.A., Inc. All rights reserved.
Connections:
Specifications:
Number of Outputs
Total Output Current
Main Fuse Rating
Output Fuse Rating
4 9 16
4 A m ps* 4 A m ps* 8 Amps*
5.0 Amps @ 250VAC
1.1 Amps @ 250VAC
EV
P-1
SA
4P
4U
L
EV
P-1
SA
4P
9U
L
EV
P-1
SA
8P
16
UL
EVP-1SA4P9UL
9 Outputs @ 24VAC (4 Amps*)
EVP-1SA8P16UL
16 Outputs @ 24VAC (8 Amps*)
EVP-1SA4P9UL shown
* Max total continuous output current, each channel output is fused at 1.1 Amp.
The ENFORCER CCTV Power Supplies centralize the power sources for multiple AC-
powered CCTV cameras and/or CCTV accessories. The power input, power transformer,
and all fused power outputs are enclosed in one heavy-duty, easy-to-install enclosure.
1 2 3 4
P
N
OFF
ON
M A IN
F U S E
LED
INPUT
110VAC
LED1 LED2 LED3 LED4
5 6 7 8
FUSED OUTPUTS
COMMON OUTPUTS
LED5 LED6 LED7 LED8
9
LED9
Main
(EVP-1S4A4P9UL shown)
ENFOR CER
5A,
250VAC
Fuse
Switch
AC Terminal
Block
Output 1:
24VAC
Power
cord
hole
Green wire
White
wire
Black
wire
