OPERATION
Operation Section 4-4
OPERATION
© 2004 Alamo Group Inc.
SR10M/SR15M 10-01
Standard Equipment and Specifications
Horsepower Required (Min.).......50 HP
40 HP
Cutting Capacity (Diameter)....... 3”
3”
Cutting Height............................1”-15”
1”-15”
Safety Deflectors*.......................Standard
Standard
Cutting Width............................ 180”
126”
Transport Width.........................90-1/2”
88”
Overall Width.............................186”
133”
Overall Length............................183”
183”
Blade Overlap.............................6”
6”
Weight (Approximate)................ 4345 lbs.
3910 lbs.
Wing Lift....................................Hydraulic
Hydraulic
Wing Flex (Degrees).................. 90° Up-22° Down
90° Up-22° Down
Jack Stand...............................
Standard
Standard
Hitch........................................
Heavy-Duty Clevis
Heavy-Duty Clevis
Blade Carrier..............................Pan
Pan
Gearbox Rating:**
Power Divider.......................180 HP
180 HP
Center & Wings...................140 HP
140 HP
Output Shaft Diameter............... 2-3/8”
2-3/8”
Blade Tip Speed
Center 540 RPM................ 14,861 FPM
14,861 FPM
1000 RPM................15,570 FPM
15,570 FPM
Wings
540 RPM.................14,242 FPM
14,242 FPM
1000 RPM...............14,624 FPM
14,624 FPM
Driveline Size:
Main (44R or CV)................ Cat 5
Cat 5
Wings................................
Cat 4 or 5
Cat 4 or 5
Deck Thickness........................ 10 Gauge
10 Gauge
Side Skirts...............................
1/4”x10-1/2”
1/4”x10-1/2”
Replaceable Skid Shoes............ Standard
Standard
*Safety Deflectors are standard equipment. Single and double chain guards are available
as extra equipment at extra cost. Servis-Rhino recommends mowers be equipped with
deflectors or double chain guards for all mowing purposes. Single chain guards may be
used for agriculture purposes only and are specifically not recommended for highway,
right-of-way, parks or greenbelt mowing.
**Ratings based on actual field performance.
SR15
SR10
