Servis-Rhino 2160 User Manual

Servis 2160, Operator’s manual

SERVIS

2160

Published 02/10

Part No. 00765708C

OPERATOR’S MANUAL

RHINO

1020 S. Sangamon Ave.
Gibson City, IL 60936
800-446-5158
Email: [email protected]

BOOM ROTARY CUTTER

This Operator's Manual is an integral part of the safe operation of this machine and must
be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW the Safety
and Operation Instructions contained in this manual before operating the equipment. C01-
Cover

$0.00

Table of contents

Document Outline

SERVIS 2160
OPERATOR’S MANUAL
- RHINO®
To the Owner/Operator/Dealer
- BOOM ROTARY CUTTER
Alamo Group Ag. Division is willing to provide
one (1) AEM Mower Safety Practices Video
TABLE OF CONTENTS
- General Safety Instructions and Practices
- Operator Safety Instructions and Practices
- Connecting & Disconnecting Implement Safety Instructions & Practices
- Equipment Operation Safety Instructions and Practices
- Maintenance and Service Safety Instructions and Practices
- Transporting Safety Instructions and Practices
- Concluding Safety Instructions and Practices
Decal Location
- 1. D389 1 DANGER Multi-Hazard
- 2. D388 1 DANGER Multi-Hazard
- 3. D401 1 WARNING 1000 RPM (Not Shown-Apply to D388 if 1000 RPM)
- 4. 02962764 2 WARNING Pinch Points
- 5. D416 1 IMPORTANT Service Hydraulic System
- 6. 02962765 1 DANGER Crushing and Pinch Points
- 7. 999001 1 WARNING Tractor Safety
- 8. 00753840 1 DANGER Stay Clear when Lowering Wing
- 9. 02965262 1 WARNING Oil Leaks
- 10. 02958241 1 DANGER Boom Safety
- 11. 00760657 1 IMPORTANT Genuine Rhino Parts
- 12. D303 2 NAME LOGO RHINO Name
- 13. 00764866 4 NAME LOGO Servis 2160 Name
- 14. D302 1 LOGO Rhino Logo (Small)
- 15. D304 2 LOGO Rhino Logo (Big)
- 16. 02965093 1 ATTENTION Do not Overspeed Engine
- 17. 02964509 2 INSTRUCT Unhitching Instructions
- 18. D395 1 IMPORTANT Replace Blades in Pairs
- 19. NFS 1 SER PLT Serial Number (Not Shown)
- 20. 1458392 1 REFLECT Red Reflector
- 21. 1458393 1 REFLECT Yellow Reflector
- 22. 03200347 * REFLECT SMV Sign
- 23. 00776031 1 ________ Canister
- 24. 10058000 3 ________ Bolt
- 25. 00024100 3 ________ Flatwasher
- 26. 02959924 3 ________ Locknut
- 27. 000678 2 INFO Grease Fitting Inside
Decal Description
- Federal Laws and Regulations
  - SAFETY SECTION
  - INTRODUCTION SECTION
- TRACTOR PREPARATION
MOWER TO TRACTOR ATTACHMENT
DRIVELINE LENGTH CHECK PROCEDURE
- 1. Separate two halves of driveline and connect one half to tractor and the other half to mower.
- 2. Lower mower to normal operating position.
- 3. Bring the two driveline halves together as shown in figure 6. At this maximum compressed length there should be 1-1/2 inches or more clearance from tubes bottoming out. If not, shorten the driveline to obtain clearance. Shorten shield tubes and sl...
- 4. Raise mower to transport position. Check driveline length at this maximum extension to make sure profile tubes are always engaged at least 8 inches.
HOSE CONNECTION
ATTACHMENT OF HYDRAULIC HOSES
- HOSE CONNECTIONS ELECTRONIC
HOSES TO VALVE CONNECTIONS FOR ELECTRONIC CONTROL (OPTIONAL)
MOUNTING THE REMOTE COMMAND HANDLE
HOSE CONNECTIONS (DIRECT)
HEAD ATTACHMENT
- HOSE ATTACHMENT
HYDRAULIC RELIEF ATTACHMENT (OPTIONAL)
- 1. Remove the top link of the three point from the tractor.
- 2. Connect the center lug (1) of the Hydraulic Relief Arm (HRA) to the tractor, with the double lugs (2) up, where the top link was removed.
- 3. Back the tractor up to the SERVIS 2160 and connect the lower arms (3) of the three point, making sure that the HRA does not interfere with the SERVIS 2160.
- 4. Attach the top link of the three point between the SERVIS 2160 and the double lugs (2) on the HRA.
- 5. Connect the SERVIS 2160 Hydraulics to the tractor so that they are functional.
- 6. Lift the three point of the tractor so that the SERVIS 2160 is at the desired height.
- 7. Carefully adjust the SERVIS 2160 hydraulics so that the lower arms (3) of the HRA align with the holes (4) on the SERVIS 2160.
- 8. Bolt the HRA arms to the SERVIS 2160.
- 9. Relieve pressure from the tractor three point.
STARTING UNIT
- 1. Make sure unit has been properly assembled, all cylinders, Hoses, and the driveline have been connected.
- 2. Run the mower for about 2 - 3 minutes to fill hydraulic lines and hoses with fluid.
- 3. Check the fluid level at sight gauge (Asm-B-0011). If oil is below sight gauge fill as required to bring to sight gauge.
- 4. Remove the filler cap. (Asm-B-0007)
- 5. Fill the hydraulic reservoir until the fluid is visible through the sight gauge. (Asm-B-0010)
- 6. Avoid hydraulic contamination by filtering the hydraulic oil while filling the hydraulic tank. Filter buggies or carts are commercially available for hydraulic system clean-up. These consist of a high-efficiency, high- capacity filter, a circulati...
- 7. When adding hydraulic oil, use only new oil from a sealed barrel. Used oil or oil from an open barrel may contain high levels of contamination. Transfer the oil into the hydraulic tank by using a hydraulic filter pump unit equipped with a properly...
- 8. Run the mower at PTO operating speed (540 or 1000 RPM) for 20 minutes while checking for any a leaks and making sure mower is operating correctly.
- ASSEMBLY SECTION
- Pre-Customer Delivery Check List
RHINO 2160 BOOM MOWER
OPERATION INSTRUCTIONS
1. Standard Equipment and Specifications
- HYDRAULIC BOOM ROTARY CUTTER
- EXTRA EQUIPMENT OPTIONAL EQUIPMENT
- 2. OPERATOR REQUIREMENTS
3. TRACTOR REQUIREMENTS
- 3.1 ROPS and Seat Belt
- 3.2 Operator Thrown Object Protection
- 3.3 Tractor Lighting and SMV Emblem
- 3.4 Tractor Ballast
- 3.5 Tractor Safety Devices
- 3.6 Front End Weight
- 3.7 Power Take Off (PTO)
- 4. GETTING ON AND OFF THE TRACTOR
  - 4.1 Boarding the Tractor
  - 4.2 Dismounting the Tractor
- 5. STARTING THE TRACTOR
- 6. SETTING THE MOWER
- 7. PRE-OPERATION INSPECTION AND SERVICE
- 8. DRIVING THE TRACTOR AND IMPLEMENT
- 9. OPERATING THE TRACTOR AND IMPLEMENT
- 10. TRACTOR, BOOM, AND ATTACHED HEAD STORAGE
- 11. TRANSPORTING THE TRACTOR AND IMPLEMENT
  - 11.1 Transporting on Public Roadways
  - 11.2 Hauling the Tractor and Implement
- 12. TROUBLESHOOTING GUIDE
  - MAINTENANCE SECTION
- LUBRICATION INFORMATION
  - Lubrication
DRIVELINE LUBRICATION
MAIN DRIVELINE & CAT 4 SAFETY SHIELD
HYDRAULIC OIL, FILTERS AND COMPONENTS
BLADES
- HARDWARE
- BLADE SERVICING
BLADE SHARPENING
- BLADE REMOVAL
BLADE CARRIER REMOVAL
- BLADE CARRIER INSPECTION
- BLADE CARRIER INSTALLATION
- BASIC TROUBLESHOOTING OF ELECTRONIC CONTROL VALVE
  - CONTROL HANDLE
    - 1. Check electrical supply with a voltmeter. Connect the positive lead from the meter to the red wire that supplies power to the handle and connect the other lead to the frame of the vehicle. Reading should be 12- 14 volts. Be certain that the ground...
    - 2. Check for power at valve or load. Connect positive lead to each of the wires that supply the load, connect the other lead to vehicle ground. Operating buttons on handle should turn each wire on/off, 12-14 volts.
    - 3. Check for proper grounding of valve or load. Connect positive lead to the valve block or to the ground connection of the load, connect the other lead to the vehicle frame (ground). There should be little or no voltage present. If there is a readin...
    - 4. If voltage is present at coil terminal and ground connection is good, check to see if solenoid coil is being energized by touching the large nut on the top of the coil with a screwdriver or small wrench. When coil is energized, the tool will light...
STORAGE
- 1. Thoroughly clean the cutter.
- 2. Lubricate the cutter as covered in Maintenance Section.
- 3. Tighten all bolts and pins to the recommended torque.
- 4. Check the cutter for worn or damaged parts. Make replacements immediately.
- 5. Store the cutter in a clean, dry place with the cutter housing resting on blocks.
- 6. Use spray touch-up enamel where necessary to prevent rust and maintain the appearance of the cutter.
- PROPER TORQUE FOR FASTENERS
TO THE OWNER/OPERATOR/DEALER
RHINO
- LIMITED WARRANTY
- 1. LIMITED WARRANTIES
- 1.01. Rhino warrants for one year from the purchase date to the original non-commercial, governmental, or municipal purchaser (“Purchaser”) and warrants for six months to the original commercial or industrial purchaser (“Purchaser”) that the ...
- 1.02. Manufacturer will replace for the Purchaser any part or parts found, upon examination at one of its factories, to be defective under normal use and service due to defects in material or workmanship.
- 1.03. This limited warranty does not apply to any part of the goods which has been subjected to improper or abnormal use, negligence, alteration, modification, or accident, damaged due to lack of maintenance or use of wrong fuel, oil, or lubricants, ...
- 1.04. Except as provided herein, no employee, agent, Dealer, or other person is authorized to give any warranties of any nature on behalf of Manufacturer.
- 2. REMEDIES AND PROCEDURES.
- 2.01. This limited warranty is not effective unless the Purchaser returns the Registration and Warranty Form to Manufacturer within 30 days of purchase.
- 2.02. Purchaser claims must be made in writing to the Authorized Dealer (“Dealer”) from whom Purchaser purchased the goods or an approved Authorized Dealer (“Dealer”) within 30 days after Purchaser learns of the facts on which the claim is based
- 2.03. Purchaser is responsible for returning the goods in question to the Dealer.
- 2.04. If after examining the goods and/or parts in question, Manufacturer finds them to be defective under normal use and service due to defects in material or workmanship, Manufacturer will:
  - (a) Repair or replace the defective goods or part(s) or
  - (b) Reimburse Purchaser for the cost of the part(s) and reasonable labor charges (as determined by Manufacturer) if Purchaser paid for the repair and/or replacement prior to the final determination of applicability of the warranty by Manufacturer.
- 2.05. Purchaser is responsible for any labor charges exceeding a reasonable amount as determined by Manufacturer and for returning the goods to the Dealer, whether or not the claim is approved. Purchaser is responsible for the transportation cost for...
- 3. LIMITATION OF LIABILITY.
- 3.01. MANUFACTURER DISCLAIMS ANY EXPRESS (EXCEPT AS SET FORTH HEREIN) AND IMPLIED WARRANTIES WITH RESPECT TO THE GOODS INCLUDING, BUT NOT LIMITED TO, MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
- 3.02. MANUFACTURER MAKES NO WARRANTY AS TO THE DESIGN, CAPABILITY, CAPACITY, OR SUITABILITY FOR USE OF THE GOODS.
- 3.03. EXCEPT AS PROVIDED HEREIN, MANUFACTURER SHALL HAVE NO LIABILITY OR RESPONSIBILITY TO PURCHASER OR ANY OTHER PERSON OR ENTITY WITH RESPECT TO ANY LIABILITY, LOSS, OR DAMAGE CAUSED OR ALLEGED TO BE CAUSED DIRECTLY OR INDIRECTLY BY THE GOODS INCLU...
- 3.04. NO ACTION ARISING OUT OF ANY CLAIMED BREACH OF THIS WARRANTY OR TRANSACTIONS UNDER THIS WARRANTY MAY BE BROUGHT MORE THAN TWO (2) YEARS AFTER THE CAUSE OF ACTION HAS OCCURRED.
- 4. MISCELLANEOUS.
- 4.01. Proper Venue for any lawsuits arising from or related to this limited warranty shall be only in Guadalupe County, Texas.
- 4.02. Manufacturer may waive compliance with any of the terms of this limited warranty, but no waiver of any terms shall be deemed to be a waiver of any other term.
- 4.03. If any provision of this limited warranty shall violate any applicable law and is held to be unenforceable, then the invalidity of such provision shall not invalidate any other provisions herein.
- 4.04. Applicable law may provide rights and benefits to purchaser in addition to those provided herein.
