Instructions for the user
13
5. DESCRIPTION OF CONTROLS
5.1 Front control panel
All the cooker controls and commands are on the front panel.
Before using the main oven check that the electronic programmer is
showing the symbol (see paragraph “5.2.1 Clock adjustment”).
DESCRIPTION OF SYMBOLS
BACK LEFT BURNER BACK RIGHT BURNER
FRONT LEFT BURNER FRONT RIGHT BURNER
FRONT CENTRAL
BURNER BACK CENTRAL
BURNER
MAIN OVEN
THERMOSTAT AUXILIARY OVEN
THERMOSTAT
MAIN OVEN
FUNCTIONS
COOKING HOB BURNER COMMAND KNOB
The flame is lit by pressing the knob and turning it
anticlockwise to maximum flame . To adjust the
flame turn the knob between maximum ( ) and
minimum ( ). The burner goes out when the knob is
returned to the position .
MAIN OVEN THERMOSTAT KNOB
Selection of cooking temperature is carried out by
turning the knob clockwise to the required temperature,
between 50° and 250°C.
The tell-tale light comes on to indicate that the oven is
warming up. When it goes out it means that the
required temperature has been reached. Regular
flashing means that oven temperature is being
constantly maintained at the programmed level.
