26
SPECIFICATIONS
Name Biomedical Freezer
Model MDF-U333 MDF-U537 MDF-U537D
External dimensions W614 x D733 x H1620 (mm) W804 x D772 x H1802 (mm) W804 x D772 x H1802 (mm)
Internal dimensions W490 x D485 x H1290 (mm) W658 x D607 x H1272 (mm)
W658 x D607 x H589 (mm)
Upper chamber
W658 x D607 x H603 (mm)
Lower chamber
Effective capacity 274 L 482 L 452 L
Exterior Painted steel
Interior Styrol resin
Insulation Rigid polyurethane foamed-in place
Outer door Painted steel
Lock 1
Caster 4
Leveling leg 2
Evaporator Tube on sheet type (also used as a shelf)
Access port
Diameter 30 mm
1 on left side
Diameter 30 mm
1 on back side
Diameter 30 mm
2 on back side
Condenser Wire and tube type
Compressor Hermetic type, 225 W Hermetic type, 350 W
Refrigerant R-134a R-407D
Temperature controller Electronics controller (between -18 and -40
o
C)
Temperature display Digital display (between -50 and +50 o C)
Temperature sensor Thermistor sensor
Temperature alarm Flash of digital indicator and alarm lamp, Buzzer, (Remote alarm)
Accessories
1 set of key, 1 scraper
4 card holders
4 large baskets
W446 x D369 x H220 (mm)
1 small basket
W487 x D221 x H155 (mm)
1 set of key, 1 scraper
14 card holders
6 large baskets for upper chamber
W290 x D536 x H136 (mm)
8 small baskets for lower chamber
W290 x D536 x H100 (mm)
Weight 81 kg 131 kg 136 kg
Battery For power failure alarm, Nickel hydrogen battery, DC 6V, 1100mAh, Automatic charge
Optional component
Automatic temperature recorder (MTR-G85)
Mounting kit for automatic temperature recorder (MPR-S7, MDF-S740T)
Note Design or specifications will be subject to change without notice.
