- 63 -

21

ROUTINE MAINTENANCE

Defrosting of inside wall

The frost is built at the upper portion of the chamber and inner door. The excessive frost possibly make

some gap between the cabinet and magnetic door gasket, which may cause poor cooling. Remove the

frost on the inner door with a scraper enclosed with the unit. Following shows the procedure for

removing the chamber frost.

Note: For removing the frost, do not use a tool with sharp edge such as a knife or a screw driver.

1. Turn off the back-up system if applicable.

2. Take out and transfer all the contents to another

freezer or a container which is refrigerated by liquid

carbon dioxide or dry ice.

3. Turn off the power switch of the freezer.

4. Open the outer door and inner door. Remove the

inner door by lifting up as shown in the figure.

5. Leave the freezer as it is.

6. The water accumulated on the bottom of the chamber

should be wiped up with a dry cloth.

7. After cleaning the chamber and inner door, replace

the inner door and start up the unit according to the

procedure on page 13.

8. Put back the articles into the sufficiently cooled

freezer compartment.

9. Turn on the back-up system if it is provided.
