Page 25
TYPICAL SPECIFICATIONS
NOISE
Measured RMS, 20Hz to 20kHz Bandwidth
Line inputs selected at unity gain and terminated 150R
AUX, MIX, SUB O/Ps 16 Inputs routed, faders & pots down
<85 dBu
E.I.N. Microphone Input, Maximum Gain, terminated 150R -129 dBu
CROSSTALK 1kHz 10kHz
Channel mute <95 dB <85 dB
Fader cutoff (rel to 0 mark) <90dB <80dB
Routing isolation <90dB <80dB
Aux Sends pots offness <85dB <80dB
FREQUENCY RESPONSE
Mic/Line In to any output
25Hz to 30kHz
<1dB
T.H.D. Mic Sens. -30dBu, +20dBu at all outputs @ 1kHz < 0.006%
INPUT & OUTPUT IMPEDANCES
Microphone Input 1.8 kW
Line Input 10 kW
Stereo Input A/B 12 kW
Stereo Input C/D 10 kW
Direct Out, Sub-Mix, Aux, Insert 75 W
INPUT & OUTPUT LEVELS
Mic Input Maximum Level +22 dBu
Line Input Maximum Level >+30dBu
Stereo Input Maximum Level >+30 dBu
Headphones (@200W) 150mW
