ATA C OMMAND B LOCK AND S ET D ESCRIPTION SSD-H XXX (I)-3500 D ATA S HEET
S ILICON S YSTEMS P ROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3500H-03DSR P AGE 51 F EBRUARY 2, 2009
Standby — 96h, E2h
When the Standby command is issued by the host, it transitions the device into
standby mode. If the Sector Count register is set to a value other than 0h, the
Auto Powerdown function is enabled and the device returns to Idle mode.
Table 52: Standby — 96h, E2h
Register D
7
D
6
D
5
D
4
D
3
D
2
D
1
D
0
Feature X
Sector Count Timer Count (5ms x Timer Count)
Sector Number X
Cylinder Low X
Cylinder High X
Drive Head X X X Drive X
Command 96h or E2h
