E LECTRICAL S PECIFICATION SSD-H XXX (I)-3500 D ATA S HEET
S ILICON S YSTEMS P ROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3500H-03DSR P AGE 9 F EBRUARY 2, 2009
A BSOLUTE M AXIMUM R ATINGS
C APACITANCE
-RESET 1 I
Device Reset.
An active low signal. When
active, this signal sets all internal registers
to their default state. This signal is held
asserted until at least 25μs after power has
been stabilized during the device power-on.
V
CC
41, 42 - Device Power Supply. The device power
5V signal.
Table 9: Signal Descriptions (Continued)
Signal Name Pin(s) Type Description
Table 10: Absolute Maximum Ratings
Symbol Parameter Minimum Maximum Units
T
s
Storage Temperature -55 125 °C
T
A
Operating Temperature -40 85 °C
V
CC
V
CC
with Respect to GND -0.3 6.7 V
V
in
Input Voltage -0.5 6.0 V
V
out
Output Voltage -0.3 5.8 V
Table 11: Capacitance
Symbol Parameter Maximum Units
C
in
Input Capacitance 35 pF
C
out
Output Capacitance 35 pF
C
I/O
Bidirectional Capacitance 35 pF
