21 US
Getting Star
ted
4 Connecting the other components
You can enjoy the connected component using the speakers of the system.
To connect the DIGITAL MEDIA PORT adapter
Connect the DIGITAL MEDIA PORT adapter to the DMPORT jack. For details, see “Using the
DIGITAL MEDIA PORT Adapter” (page 62).
Note
• Connect the DIGITAL MEDIA PORT adapter so that the V marks are aligned. When disconnecting, pull out while
pressing A.
• Do not connect or disconnect the DIGITAL MEDIA PORT adapter to/from the control unit while the system is
turned on.
Tip
• You can assign a digital sound input corresponding with the function “TV” and “SAT/CABLE.” For details,
see [DIGITAL IN] (page 84).
DMPORT
A B
Rear of the control unit
DIGITAL MEDIA PORT adapter
Digital coaxial cord
(not supplied)
To the digital coaxial output
jack of another component
(e.g.: digital satellite receiver)
A
continued
