- 6 -
The appliance components
q Mounting plate/Baseplate
w Power cable
e Wire aerial
r Display
t POWER - On/Off switch for radio function
y TIMER - controls the timer programming
u VOL. — Volume reduction
ALARM SET q - controls the alarm function 1
i VOL. + Volume increase
ALARM SET w - controls the alarm function 2
o Battery compartment
a MEM. 01-10 - for saving radio stations
s MEM. 11-20 - for saving radio stations
d A.O.T. - controls the switch-off timer
f STORE/Key-Lock - Save button/Button lock
g T DOWN T - Selection button downwards
h S UP S - Selection button upwards
j
MODE SET/X-BASS - switches the display options,
activates the Extra-Bass function
Fixing the kitchen radio beneath a wall cabinet
With the supplied mounting plate q you can fix the kitchen
radio below, for example, a kitchen wall cabinet:
1. Determine a suitable location for the kitchen radio.
2. Press the two retaining levers on the back of the appliance
down. Push the mounting plate q back and remove it.
3. Place the mounting plate q against the installation location.
Allow 3 cm space to the front edges.
This way the kitchen radio will later fit flush.
4. Mark the four points for the drillholes with a pencil.
5. Mark the drillhole with a mandril. Firmly secure the
mounting plate q with the supplied screws.
6. Hold the kitchen radio slanted, with the two recesses in
the retaining lugs on the mounting plate q.
Press the kitchen radio upwards until it audibly engages.
