1. Connect the [RGB/COMPONENT IN] ports on the monitor to the P
R
, Y, P
B
ports on the
set-top box using the D-Sub to Component cable.
2. Connect a set of audio cables between the [AV COMPONENT AUDIO IN [L-AUDIO-R]]
on the LCD Display and the AUDIO OUT jacks on the Set Top Box.
Note
• Select Component using the SOURCE button on the front of the LCD Display or on the
remote control.
• For an explanation of Component video, see your Set Top Box owner's manual.
Connecting to an Audio System
1. Connect a set of audio cables between the AUX L, R jacks on the AUDIO SYSTEM and
[AUDIO OUT] on LCD Display.
Connecting a wireless microphone
1. Connect a wireless microphone sensor unit to [MIC IN] on the monitor.
Note
To use a wireless microphone, Wireless MIC must be set to On in the Sound menu.
Connections
