5 FLEXIBLE HOSE AND HOSE
CONNECTOR
• Remove Hose Connector from the
Vacuum.
•
Detach the Flexible Hose from the
Hose Connector by squeezing the
tabs and gently pulling out. ( fig. e)
• Check inside the Hose.
• Check inside the Hose Connector.
• Check the Vacuum Inlet Opening.
• Snap the Flexible Hose back onto
the Hose Connector by aligning the
tabs on the Hose with the holes on
the Hose Connector and pushing the
two pieces together until they click
back into place. ( fig. f)
To reduce the risk of electric shock,
unplug the unit before performing
any cleaning, maintenance, or
troubleshooting checks.
WARNING: Never insert sharp
objects into any opening to clear an
obstruction.
IMPORTANT: Damages caused
while clearing or attempting to clear
blockages are not covered under
your product’s limited warranty.
Reassemble all parts securely before
operating vacuum.
e f
Troubleshooting Guide
PROBLEM POSSIBLE REASONS & SOLUTIONS
Vacuum is not
picking up dirt.
Check Filters to see if they need cleaning. Follow
instructions for rinsing and drying the Filters before re-
inserting back into the Vacuum. (See “Maintenance”
sections for instructions.)
Dust Cup may be full; empty Dust Cup.
Check Hose and Hose connections for blockages; clear
blockages if required.
If Dust Cup is empty, and attachment inlets are clear, check
for other blockages. (See “Checking for Blockages” for
instructions.)
Vacuum lifts scatter
rugs (lightweight,
movable rugs).
Because the suction is powerful, take care when vacuuming
scatter-type rugs or rugs with delicately sewn edges.
Airflow is restricted.
No suction or light
suction.
Check Filters to see if they need cleaning. Follow
instructions for rinsing and drying the Filters before re-
inserting back into the Vacuum. (See “Maintenance”
sections for instructions.)
Dust Cup may be full; empty Dust Cup.
Check Hose and Hose connections for suction strength;
clear blockages if required.
If Dust Cup is empty, and attachment inlets are clear, check
for other blockages. (See “Checking for Blockages” for
instructions.)
Vacuum turns off
on its own.
This vacuum cleaner is equipped with a motor protective
thermostat. If for some reason your vacuum overheats, the
thermostat will automatically turn the unit off. Should this
occur, perform the following steps to restart the motor
thermostat:
1. Move the Power Button to the “O” (Off) position.
2. Unplug the vacuum.
3. Empty the Dust Cup and clean Filters. (See
“Maintenance” sections for instructions.)
4. Check for blockages in hose, accessories and inlet
opening. (See “Checking for Blockages” for instructions.)
5. Allow the unit to cool for a minimum of 45 minutes.
6. Plug in the vacuum.
7. Turn the Power Switch to the “I” (On) position to restart
the vacuum.
Note: If vacuum still does not start, contact Customer
Service at: 1-800-798-7398.
