SPECIFICATIONS
Camera:
Scanning system : NTSC standard TV system (525 TV
lines, 30 frames/sec.)
Interlace : PLL 2:1 interlace
Image device : 1/3 inch solid state image device
CCD
Picture elements : 811 (H) x 508 (V)
Effective picture elements : 768 (H) x 494 (V)
Synchronizing system : Internal sync, Line lock manually
switchable
Resolution : 470 TV lines horizontally, 350 TV
lines vertically
Video output level : 1.0 Vp-p/75 ohms, composite
Video S/N ratio : More than 48 dB
Minimum required
illumination
(incandescent lighting) : Approx. 0.07 lux with a F 1.2 lens
(B/W mode),
Approx. 1.4 lux with a F 1.2 lens (color
mode)
Control terminal : Manual color/black and white setting
Backlight compensation : Manual ON/OFF switching,
Multi-zone light measuring system
(Active when using an auto-iris lens)
Iris function : Manual ON/OFF switching
Electronic iris range : 1.4 lux to 70,000 lux (F 1.2, lens:
color mode)
2.0 lux to 100,000 lux (F 1.4, lens:
color mode)
Flange-back : 12.5 mm ± 0.5 mm
White balance : ATW/Manual switching
Lens mount : CS mount (or C mount with the
supplied adaptor)
Environmental conditions : Temperature: –10˚C ~ +50˚C
Humidity: less than 90% (no
condensation)
Power supply : 24 V AC, 60 Hz
Power consumption : 3.8 W (with auto iris lens)
3.0 W (without auto iris lens)
Weight : Approx. 450 g (without lens)
